Tektronix MSO4102B
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Analog Channels | 2 |
| Number of Digital Channels | 16 |
| Sample Rate | 5 GS/s |
| Record Length | 20 M points |
| Vertical Resolution | 8 bits |
| Display | 10.4 inch WSVGA color LCD touchscreen |
| Waveform Capture Rate | Up to 340,000 waveforms per second |
| Input Impedance | 1 MΩ or 50 Ω |
| Connectivity | USB, LAN (LXI), GPIB (optional) |
Tektronix MSO4102B Options:
- MSO4102B - DPO4BND - Application bundle module that enables all of the functionality of the DPO4AERO, DPO4AUDIO, DPO4AUTO, DPO4COMP, DPO4EMBD, DPO4ENET, DPO4LMT, DPO4PWR, DPO4USB and DPO4VID application modules in a single module
- MSO4102B - DPO4AERO - Aerospace Serial Triggering and Analysis Module (MIL-STD-1553)
- MSO4102B - DPO4AUDIO - Audio Serial Triggering and Analysis Module (I2S, LJ, RJ, TDM)
- MSO4102B - DPO4AUTO - Automotive Serial Triggering and Analysis Module (CAN and LIN)
- MSO4102B - DPO4AUTOMAX - Extended Automotive Serial Triggering and Analysis Module (CAN, LIN, and FlexRay)
- MSO4102B - DPO4COMP - Computer Serial Triggering and Analysis Module (RS-232/422/485/UART)
- MSO4102B - DPO4EMBD - Embedded Serial Triggering and Analysis Module (I2C and SPI)
- MSO4102B - DPO4ENET - Ethernet Serial Triggering and Analysis Module (10BASE-T and 100BASE-TX)
- MSO4102B - DPO4USB - USB Serial Triggering and Analysis Module (low-speed, full-speed, and high-speed)
- MSO4102B - DPO4PWR - Power Analysis Application Module
- MSO4102B - DPO4LMT - Limit and Mask Testing Application Module
- MSO4102B - DPO4VID - HDTV and Custom (nonstandard) Video Triggering and Video Picture Module
- MSO4102B - A0 - North America power plug (115 V, 60 Hz)
- MSO4102B - A1 - Universal Euro power plug (220 V, 50 Hz)
- MSO4102B - A2 - United Kingdom power plug (240 V, 50 Hz)
- MSO4102B - A3 - Australia power plug (240 V, 50 Hz)
- MSO4102B - A5 - Switzerland power plug (220 V, 50 Hz)
- MSO4102B - A6 - Japan power plug (100 V, 50/60 Hz)
- MSO4102B - A10 - China power plug (50 Hz)
- MSO4102B - A11 - India power plug (50 Hz)
- MSO4102B - A12 - Brazil power plug (60 Hz)
- MSO4102B - A99 - No power cord
- MSO4102B - L0 - English manual
- MSO4102B - L1 - French manual
- MSO4102B - L2 - Italian manual
- MSO4102B - L3 - German manual
- MSO4102B - L4 - Spanish manual
- MSO4102B - L5 - Japanese manual
- MSO4102B - L6 - Portuguese manual
- MSO4102B - L7 - Simplified Chinese manual
- MSO4102B - L8 - Traditional Chinese manual
- MSO4102B - L9 - Korean manual
- MSO4102B - L10 - Russian manual
- MSO4102B - L99 - No manual
- MSO4102B - C3 - Calibration Service 3 Years
- MSO4102B - C5 - Calibration Service 5 Years
- MSO4102B - D1 - Calibration Data Report
- MSO4102B - D3 - Calibration Data Report 3 Years (with Opt. C3)
- MSO4102B - D5 - Calibration Data Report 5 Years (with Opt. C5)
- MSO4102B - R5 - Repair Service 5 Years (including warranty)
- MSO4102B - SILV600 - Standard warranty extended to 5 years
| Model | MSO4102B |
|---|
The Tektronix MSO4102B Mixed Signal Oscilloscope combines 2 analog and 16 digital channels with 1 GHz bandwidth and 5 GS/s sample rate, enabling deep signal analysis. It features Wave Inspector® controls, 20M record length, and automated measurement tools for rapid waveform evaluation. With optional serial analysis support for various protocols and TekVPI® probe interface, it ensures compatibility with a wide range of probes and applications.
Designed for engineers, it supports power analysis, limit mask testing, and video standards. Multiple USB ports and Ethernet allow flexible data export and device integration.
Testwall can supply the used Tektronix MSO4102B Mixed Signal Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix MSO4102B Mixed Signal Oscilloscope.
