Tektronix MSO54 5-BW-2000
| Attribute | Value |
|---|---|
| Bandwidth | 2 GHz |
| Number of Analog Channels | 4 |
| Sample Rate | 6.25 GS/s |
| Record Length | 31.25 M points standard |
| Digital Channels | 48 channels (with TLP058 logic probe) |
| Vertical Resolution | 12-bit ADC |
| Display | 15.6-inch HD (1920 x 1080) capacitive touchscreen |
| Waveform Capture Rate | 500,000 waveforms per second |
| Connectivity | USB 3.0, USB 2.0, LAN (1000BASE-T), DisplayPort |
| Operating System | Windows 10 (64-bit) |
Tektronix MSO54 5-BW-2000 Options:
Options available for the Tektronix 5 Series MSO. Installed options vary from unit to unit – ask us for the exact configuration of the instrument you are interested in.
- MSO54 - 5-BW-2000 - 2 GHz analog bandwidth (this unit)
- MSO54 - 5-AFG - Built-in 50 MHz arbitrary/function generator
- MSO54 - 5-RL-125M - Record length extension to 125 M points per channel
- MSO54 - 5-RL-250M - Record length extension to 250 M points per channel
- MSO54 - 5-RL-500M - Record length extension to 500 M points per channel
- MSO54 - 5-WIN - Removable SSD with Windows operating system
- MSO54 - 5-SEC - Enhanced security for instrument declassification
- MSO54 - 5-DJA - Advanced jitter and eye analysis
- MSO54 - 5-PWR - Advanced power measurement and analysis
- MSO54 - 5-PS2 - Power solution bundle (5-PWR, THDP0200, TCP0030A, deskew fixture)
- MSO54 - 5-DPM - Digital power management analysis
- MSO54 - 5-IMDA - Inverter / motor drive analysis
- MSO54 - 5-MTM - Mask and limit testing
- MSO54 - 5-SV-RFVT - Spectrum View RF versus time analysis
- MSO54 - 5-SV-BW-1 - Spectrum View capture bandwidth increased to 500 MHz
- MSO54 - 5-VID - Analog video triggering (NTSC, PAL, SECAM)
- MSO54 - 5-UDFLT - User-defined filter creation tool
- MSO54 - 5-CMUSB2 - USB 2.0 automated compliance (TekExpress)
- MSO54 - 5-CMENET - Ethernet 10/100/1000BASE-T automated compliance (TekExpress)
- MSO54 - 5-CMAUTOEN - Automotive Ethernet automated compliance (TekExpress)
- MSO54 - 5-DBLVDS - TekExpress automated LVDS test
- MSO54 - 5-SRAERO - Aerospace serial triggering and analysis (MIL-STD-1553, ARINC 429)
- MSO54 - 5-SRAUDIO - Audio serial triggering and analysis (I2S, LJ, RJ, TDM)
- MSO54 - 5-SRAUTO - Automotive serial triggering and analysis (CAN, CAN FD, LIN, FlexRay)
- MSO54 - 5-SRAUTOSEN - Automotive sensor serial triggering and analysis (SENT)
- MSO54 - 5-SRCOMP - Computer serial triggering and analysis (RS-232/422/485, UART)
- MSO54 - 5-SREMBD - Embedded serial triggering and analysis (I2C, SPI)
- MSO54 - 5-SRENET - Ethernet serial triggering and analysis (10BASE-T, 100BASE-TX)
- MSO54 - 5-SRI3C - I3C serial triggering and analysis
- MSO54 - 5-SRPM - Power management serial triggering and analysis (SPMI)
- MSO54 - 5-SRUSB2 - USB 2.0 serial triggering and analysis (LS, FS, HS)
The Tektronix MSO54-5-BW-2000 offers 2 GHz bandwidth, 4 FlexChannels, and a real-time sample rate of 6.25 GS/s across all analog/digital channels, with 62.5Mpoints record length and optional expansion
Ideal for embedded systems, automotive electronics, and power supply design, its 15.6" HD display enhances visibility into complex systems and multi-signal analysis
Testwall can supply the used Tektronix MSO54-5-BW-2000, fully tested
With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality
Please contact us directly if you need calibration or repair of the Tektronix MSO54-5-BW-2000.
