Tektronix MSO54 Mixed Signal Oscilloscope,4 FlexChannel inputs Oscilloscope
Mixed Signal Oscilloscope,4 FlexChannel? inputs Oscilloscope
500 MHz (upgradeable to 1 GHz, 1.5 GHz, or 2 GHz) Bandwidth
4 FlexChannel inputs (each channel can be used as 1 analog or 8 digital channels) Number of Channels
6.25 GS/s on all channels simultaneously Sample Rate
31.25 M points standard on all channels Record Length
12-bit ADC (16-bit with High Res mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz (upgradeable to 1 GHz, 1.5 GHz, or 2 GHz) |
| Number of Channels | 4 FlexChannel inputs (each channel can be used as 1 analog or 8 digital channels) |
| Sample Rate | 6.25 GS/s on all channels simultaneously |
| Record Length | 31.25 M points standard on all channels |
| Vertical Resolution | 12-bit ADC (16-bit with High Res mode) |
| Display | 15.6-inch HD (1920 x 1080) capacitive touchscreen display |
| Digital Channels | Up to 32 digital channels when using TLP058 FlexChannel probes |
| Waveform Capture Rate | 500,000 waveforms per second |
| Serial Bus Triggering and Analysis | Supports I2C, SPI, RS-232/422/485/UART, USB 2.0, CAN, CAN FD, LIN, FlexRay, MIL-STD-1553, SENT, and more |
| Connectivity and Ports | USB 3.0 host ports, USB device port, HDMI output, LAN (RJ-45), and optional Wi-Fi |
Tektronix MSO54 Mixed Signal Oscilloscope,4 FlexChannel inputs Oscilloscope Options:
- MSO54 - 5-BW-350 - 350 MHz analog channel bandwidth
- MSO54 - 5-BW-500 - 500 MHz analog channel bandwidth
- MSO54 - 5-BW-1000 - 1 GHz analog channel bandwidth
- MSO54 - 5-BW-2000 - 2 GHz analog channel bandwidth
- MSO54 - 5-RL-125M - Extend record length to 125 Mpoints/channel
- MSO54 - 5-WIN - Add removable SSD with Microsoft Windows 10 operating system license
- MSO54 - 5-AFG - Add Arbitrary / Function Generator
- MSO54 - 5-SEC - Add enhanced security for instrument declassification and password protected enabling and disabling of all USB and Ethernet ports and firmware upgrade
- MSO54 - 5-SRAERO - Aerospace serial bus triggering, decode, and search (MIL-STD-1553, ARINC 429)
- MSO54 - 5-SRAUDIO - Audio serial bus triggering, decode, and search (I2S, LJ, RJ, TDM)
- MSO54 - 5-SRAUTO - Automotive serial bus triggering, decode, and search (CAN, CAN FD, LIN, FlexRay)
- MSO54 - 5-SRAUTOSEN - Automotive sensor serial bus triggering, decode, and search (SENT)
- MSO54 - 5-SRCOMP - Computer serial bus triggering, decode, and search (RS-232/422/485/UART)
- MSO54 - 5-SREMBD - Embedded serial bus triggering, decode, and search (I2C, SPI)
- MSO54 - 5-SRENET - Ethernet serial bus triggering, decode, and search (10BASE-T, 100BASE-TX)
- MSO54 - 5-SRPM - Power Management serial bus triggering, decode, and search (SPMI)
- MSO54 - 5-SRUSB2 - USB serial bus triggering, decode, and search (USB2.0 LS, FS, HS)
- MSO54 - 5-CMAUTOEN - Automotive Ethernet automated compliance test solution (100BASE-T1 and 1000BASE-T1)
- MSO54 - 5-CMUSB2 - USB 2.0 automated compliance test solution
- MSO54 - 5-DJA - Advanced Jitter and Eye Analysis
- MSO54 - 5-PWR - Power Measurement and Analysis
- MSO54 - 5-PS2 - Power Solution Bundle (5-PWR, THDP0200, TCP0030A, 067-1686-xx deskew fixture)
- MSO54 - HC5 - Hard carrying case
- MSO54 - RM5 - Rackmount kit
- MSO54 - A0 - North America power plug (115 V, 60 Hz)
- MSO54 - A1 - Universal Euro power plug (220 V, 50 Hz)
- MSO54 - A2 - United Kingdom power plug (240 V, 50 Hz)
- MSO54 - A3 - Australia power plug (240 V, 50 Hz)
- MSO54 - A5 - Switzerland power plug (220 V, 50 Hz)
- MSO54 - A6 - Japan power plug (100 V, 50/60 Hz)
- MSO54 - A10 - China power plug (50 Hz)
- MSO54 - A11 - India power plug (50 Hz)
- MSO54 - A12 - Brazil power plug (60 Hz)
- MSO54 - A99 - No power cord
- MSO54 - T3 - Three Year Total Protection Plan
- MSO54 - T5 - Five Year Total Protection Plan
- MSO54 - R5 - Standard Warranty Extended to 5 Years
- MSO54 - C3 - Calibration service 3 Years
- MSO54 - C5 - Calibration service 5 Years
- MSO54 - D1 - Calibration Data Report
- MSO54 - D3 - Calibration Data Report 3 Years (with Option C3)
- MSO54 - D5 - Calibration Data Report 5 Years (with Option C5)
| Model | MSO54 |
|---|
The Tektronix MSO54 features 4 FlexChannel inputs, each configurable as 1 analog or 8 digital signals, supporting bandwidths from 350 MHz to 2 GHz. It includes a 15.6" HD touchscreen with a user-friendly interface, 6.25 GS/s sample rate, and record length of 125 Mpts/channel. Enhanced resolution up to 16 bits improves precision.
Ideal for advanced analysis, this scope offers optional arbitrary/function generation, Windows OS integration, and unmatched signal visibility. FlexChannel reconfigurability ensures adaptability across diverse test needs.
Testwall can supply the used Tektronix MSO54, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix MSO54.
