Tektronix
Tektronix P6717
General Purpose Logic Probe, 17 Ch., for MSO70000 series
Logic Probe Probe Type
17 Channels Number of Channels
TLA Series Logic Analyzers Compatible Instruments
-6V to +6V Input Voltage Range
-2V to +4V Threshold Range
| Attribute | Value |
|---|---|
| Probe Type | Logic Probe |
| Number of Channels | 17 Channels |
| Compatible Instruments | TLA Series Logic Analyzers |
| Input Voltage Range | -6V to +6V |
| Threshold Range | -2V to +4V |
| Maximum Input Frequency | Up to 500 MHz |
| Input Impedance | 100 kΩ |
| Input Capacitance | 1.5 pF |
| Connector Type | Mictor Connector |
| Cable Length | 1.2 m (approximately 4 ft) |
| Model | P6717 |
|---|
The Tektronix P6717 logic probe connects MSO70000 Series oscilloscopes to digital systems, offering 16 data channels and one clock/data channel. Each lead provides both signal and ground for optimal measurement stability.
Users can connect leads individually or group them using tip holders for convenient interfacing with dense circuit environments.
Testwall can supply the used Tektronix P6717, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P6717.
