Tektronix
Tektronix P7313
Active Differential Probe, 12.5 GHz
12.5 GHz Bandwidth
28 ps Rise Time
50 Ω Input Impedance
±400 mV Dynamic Range
Less than 4 ns (typical) Propagation Delay
| Attribute | Value |
|---|---|
| Bandwidth | 12.5 GHz |
| Rise Time | 28 ps |
| Input Impedance | 50 Ω |
| Dynamic Range | ±400 mV |
| Propagation Delay | Less than 4 ns (typical) |
| Compatible Oscilloscopes | Tektronix DPO/DSA/MSO70000 Series |
| Connector Type | SMA |
| Cable Length | Approximately 1.2 m (46 in) |
| Probe Interface | TekConnect |
| Operating Temperature | 0°C to +50°C |
Tektronix P7313 Options:
- P7313 - C3 - Calibration Service 3 Years
- P7313 - C5 - Calibration Service 5 Years
- P7313 - D1 - Calibration Data Report
- P7313 - D3 - Calibration Data Report 3 Years (with Opt. C3)
- P7313 - D5 - Calibration Data Report 5 Years (with Opt. C5)
- P7313 - G3 - Complete Care 3 Years (includes loaner, discount on scheduled calibration and more)
- P7313 - G5 - Complete Care 5 Years (includes loaner, discount on scheduled calibration and more)
- P7313 - R3 - Repair Service 3 Years
- P7313 - R5 - Repair Service 5 Years
- P7313 - L0 - English manual
- P7313 - L5 - Japanese manual
- P7313 - L7 - Simplified Chinese manual
- P7313 - R3DW - Repair Service Coverage 3 Years (includes product warranty period); 3-year period starts at time of customer instrument purchase
- P7313 - R5DW - Repair Service Coverage 5 Years (includes product warranty period); 5-year period starts at time of customer instrument purchase
| Model | P7313 |
|---|
The Tektronix P7313SMA differential probe delivers high fidelity and low noise for real-time oscilloscope measurements, with >13 GHz bandwidth and 50 Ω SMA inputs for precise high-speed signal analysis.
It features DSP filtering, phase-matched SMA cables, selectable gain, and internal/external termination voltage control—ideal for HDMI, USB, PCIe, and DisplayPort standards.
Testwall can supply the used Tektronix P7313, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P7313.
