Tektronix
Tektronix PED3201
1 Channel Error Detector 32 Gb/s
32 Number of Channels
Digital Probe Probe Type
Tektronix MSO/DPO5000, MSO/DPO7000, and MSO/DPO70000 Series Oscilloscopes Compatibility
-20V to +30V Input Voltage Range
±30V Maximum Input Voltage
| Attribute | Value |
|---|---|
| Number of Channels | 32 |
| Probe Type | Digital Probe |
| Compatibility | Tektronix MSO/DPO5000, MSO/DPO7000, and MSO/DPO70000 Series Oscilloscopes |
| Input Voltage Range | -20V to +30V |
| Maximum Input Voltage | ±30V |
| Threshold Range | -8V to +8V |
| Input Impedance | 100 kΩ || 3 pF |
| Minimum Signal Swing | 500 mV |
| Cable Length | 0.3 m (12 in.) |
| Lead Set Included | Yes, includes 16-channel digital lead sets |
Tektronix PED3201 Options:
- PED3201 - HCLK - Half rate clock input option for PED3201
- PED3201 - FLCLK - Full rate clock input option for PED3201
- PED3201 - A0 - North America power plug (115 V, 60 Hz)
- PED3201 - A1 - Universal Euro power plug (220 V, 50 Hz)
- PED3201 - A2 - United Kingdom power plug (240 V, 50 Hz)
- PED3201 - A6 - Japan power plug (100 V, 50/60 Hz)
- PED3201 - A10 - China power plug (50 Hz)
- PED3201 - A11 - India power plug (50 Hz)
- PED3201 - A99 - No power cord
| Model | PED3201 |
|---|
