Tektronix TDS2014B
| Attribute | Value |
|---|---|
| Number of Channels | 4 |
| Bandwidth | 100 MHz |
| Sample Rate | 1 GS/s |
| Record Length | 2500 points on all channels |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Display | 5.7-inch color LCD |
| Input Impedance | 1 MΩ in parallel with 20 pF |
| Connectivity | USB host and device ports for data storage and PC communication |
| Model | TDS2014B |
|---|
The Tektronix TDS2014B is a 4-channel digital storage oscilloscope delivering 100 MHz bandwidth and 1 GS/s sampling rate, ideal for electronic signal diagnostics. It features a bright color LCD for superior waveform visibility and supports intuitive Autoset, Probe Check, and Help functions from the B-series. The unit retains a 2.5 kpt memory depth and includes USB connectivity for efficient data export, with optional expansion compatibility. Enhanced front-panel logic with fixed controls ensures a fast and reliable interface for streamlined operation.
This model is optimal for engineers requiring real-time waveform capture and dependable triggering, with seamless integration into standard lab workflows. The familiar user interface boosts productivity and reduces training time.
Testwall can supply the used Tektronix TDS2014B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TDS2014B.
