Tektronix TDS3052C
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Number of Channels | 2 |
| Sample Rate | 5 GS/s |
| Record Length | 10,000 points |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 1 ns/div to 10 s/div |
| Display | Color LCD, 640 x 480 resolution |
| Trigger Types | Edge, Video, Pulse Width, Logic, Serial (with optional modules) |
| Connectivity/Interfaces | USB, CompactFlash, GPIB (optional), RS-232 |
Tektronix TDS3052C Options:
- TDS3052C - Opt. A0 - North America Power Cord
- TDS3052C - Opt. A1 - Universal Euro Power Cord
- TDS3052C - Opt. A2 - United Kingdom Power Cord
- TDS3052C - Opt. A3 - Australia Power Cord
- TDS3052C - Opt. A5 - Switzerland Power Cord
- TDS3052C - Opt. A6 - Japan Power Cord
- TDS3052C - Opt. A10 - China Power Cord
- TDS3052C - Opt. A11 - India Power Cord
- TDS3052C - Opt. A99 - No Power Cord
- TDS3052C - Opt. L0 - English Manual
- TDS3052C - Opt. L1 - French Manual
- TDS3052C - Opt. L2 - Italian Manual
- TDS3052C - Opt. L3 - German Manual
- TDS3052C - Opt. L4 - Spanish Manual
- TDS3052C - Opt. L5 - Japanese Manual
- TDS3052C - Opt. L6 - Portuguese Manual
- TDS3052C - Opt. L7 - Simplified Chinese Manual
- TDS3052C - Opt. L8 - Traditional Chinese Manual
- TDS3052C - Opt. L9 - Korean Manual
- TDS3052C - Opt. L10 - Russian Manual
- TDS3052C - Opt. L99 - No Manual
- TDS3052C - Opt. CA1 - Single calibration event or coverage for the designated calibration interval, whichever comes first
- TDS3052C - Opt. C3 - Calibration Service – 3 Years
- TDS3052C - Opt. C5 - Calibration Service – 5 Years
- TDS3052C - Opt. D1 - Calibration Data Report
- TDS3052C - Opt. D3 - Calibration Data Report – 3 Years (with Option C3)
- TDS3052C - Opt. D5 - Calibration Data Report – 5 Years (with Option C5)
- TDS3052C - Opt. R5 - Repair Service – 5 Year
| Model | TDS3052C |
|---|
The Tektronix TDS3052C is a 500 MHz, 2-channel digital phosphor oscilloscope with 5 GS/s sampling rate and DRT sampling technology, offering accurate waveform analysis across all channels simultaneously. Compact at 5.9 inches deep and weighing only 7 lbs, it supports sin(x)/x interpolation, advanced triggering, and 10k record length per channel. It also features WaveAlert anomaly detection and a built-in Ethernet port for remote control.
Ideal for digital design, telecom testing, power supply development, and educational purposes, it comes equipped with a USB host port, FFT, 25 auto measurements, and OpenChoice PC communication for streamlined analysis and reporting.
Testwall can supply the used Tektronix TDS3052C, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TDS3052C
