Tektronix TDS540D
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Sample Rate | 1 GS/s (single channel), 500 MS/s (all channels) |
| Number of Channels | 4 |
| Record Length | 50,000 points per channel |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 500 ps/div to 10 s/div |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | Color LCD, 640 x 480 resolution |
| Connectivity / Storage | GPIB, RS-232, Centronics, floppy disk drive |
| Model | TDS540D |
|---|
The Tektronix TDS540D is a 500 MHz, 4-channel Digital Phosphor Oscilloscope designed to capture complex signals with high fidelity. It offers a 2 GS/s sample rate, 50 kPts record length, 1% vertical accuracy, and advanced math capabilities. Features include 1 ns peak detect, 1 mV to 10 V/div sensitivity, and up to 1 GHz differential measurement support.
Ideal for troubleshooting, design, and production testing, the TDS540D provides histogram analysis, FastFrame timestamping, and communication signal analysis with SONET/SDH and Fibre Channel capabilities.
Testwall can supply the used Tektronix TDS540D, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TDS540D.
