Tektronix TLA7D1
| Attribute | Value |
|---|---|
| Number of Channels | 136 Channels |
| Maximum Sample Rate | 2 GHz Timing, 235 MHz State |
| Memory Depth | 128 Mb per Channel |
| Threshold Voltage Range | -2.0 V to +4.0 V |
| Minimum Detectable Pulse Width | 500 ps |
| Input Impedance | 100 kΩ ± 2% in parallel with 8 pF |
| Maximum Input Voltage | ±15 V (DC + Peak AC) |
| Threshold Accuracy | ±(100 mV + 3% of threshold setting) |
| Module Slot Compatibility | Tektronix TLA7000 Series Mainframe |
| Probing System | P6960 and P6980 Series Logic Analyzer Probes |
Tektronix TLA7D1 Options:
- TLA7D1 - A1 - Universal Euro 220 VAC; 50 Hz power plug
- TLA7D1 - A2 - UK 240 VAC; 50 Hz power plug
- TLA7D1 - A3 - Australian 240 VAC; 50 Hz power plug
- TLA7D1 - A4 - North American 240 VAC; 60 Hz power plug
- TLA7D1 - A5 - Switzerland 220 VAC; 50 Hz power plug
- TLA7D1 - A99 - No Power Cord
- TLA7D1 - IN - Product installation service (on-site configuration and user familiarization; excluding network integration)
- TLA7D1 - R3 - Extends depot repair warranty service period to three years
- TLA7D1 - S1 - Uplifts standard one-year warranty service to on-site service
- TLA7D1 - S3 - Uplifts Opt. C3 and/or R3 to on-site service (must be ordered with Opt. C3 and/or R3)
- TLA7D1 - C3 - Three years of Calibration Service (includes initial calibration and two annual calibrations)
- TLA7D1 - D1 - Add calibration test data report
- TLA7D1 - D3 - Provides test data for each calibration (must be ordered with Opt. C3)
| Model | TLA7D1 |
|---|
The Tektronix TLA7D1 is a 500 MHz, 2-channel, 2.5 GS/s digital oscilloscope module designed for integration with the TLA Family of Logic Analyzers. It features advanced triggering capabilities such as Pulse Width, Runt, Glitch, Slew Rate, and more, with a 15 Kb memory depth per channel. It supports precise signal correlation with digital modules and provides high-fidelity analog views at up to 1 GHz bandwidth and 5 GS/s sample rate.
Ideal for troubleshooting, design validation, and production testing, this module delivers detailed insight into analog characteristics of digital signals with flexible cross-triggering functionality.
Testwall can supply the used Tektronix TLA7D1, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TLA7D1.
