Tektronix TVS621
| Attribute | Value |
|---|---|
| Number of Channels | 8 Analog Channels |
| Bandwidth | 200 MHz |
| Sample Rate | 2.5 GS/s |
| Record Length | 15,000 Points per Channel |
| Vertical Resolution | 8-bit |
| Input Impedance | 1 MΩ or 50 Ω |
| Time Base Range | 1 ns/div to 10 s/div |
| Display Type | Color LCD Display |
| Trigger Types | Edge, Pulse Width, Logic, Setup/Hold, Video |
| Connectivity/Interface | GPIB, RS-232, Parallel Port |
| Model | TVS621 |
|---|
The Tektronix TVS621 Waveform Analyzer features a 6.5-inch color TFT LCD with 640x480 resolution, 2-channel input, and supports DC to 1 GHz frequency range. It offers 1 GS/s sample rate, 2.5k memory depth, and multiple trigger types. Measurement functions include amplitude, frequency, rise/fall time, overshoot, and more, with RS-232, GPIB, and VGA interfaces.
Ideal for analyzing complex signals in electronics and telecom, it ensures precision across voltage, timing, and signal integrity measurements with its 50 Ohm impedance and wide sensitivity range.
Testwall can supply the used Tektronix TVS621, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TVS621.
