Wayne Kerr 65120B
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz to 120 MHz |
| Measurement Parameters | Z, Y, R, X, G, B, L, C, D, Q, θ, |Z|, |Y| |
| Basic Impedance Accuracy | 0.05% |
| Test Signal Level (Voltage) | 5 mV to 1 V RMS |
| Test Signal Level (Current) | 100 µA to 20 mA RMS |
| Impedance Range | 1 mΩ to 100 MΩ |
| Display | 7-inch color TFT LCD touchscreen |
| Interface / Connectivity | USB, LAN (LXI), GPIB (optional) |
| DC Bias Voltage | 0 to ±40 V |
| DC Bias Current | 0 to ±100 mA |
Wayne Kerr 65120B Options:
- 65120B - /B1 - Bin handler (non-isolated 5V), 25-way D-type connector, 10 bins with absolute and percentage limits
- 65120B - /B2 - Bin handler (isolated 24V), 25-way D-type connector, 10 bins with absolute and percentage limits
- 65120B - /D1 - DC Bias (0 to +40V, 0 to +100mA)
- 65120B - /D2 - DC Bias (-40V to +40V)
- 65120B - /E - Equivalent Circuit Analysis firmware option
- 65120B - /K - Material Test firmware option (Calculates Complex Relative Permittivity and Complex Permeability)
- 65120B - /M - Multi-Measurement Mode firmware option
- 65120B - /Y - Polar Complex Plots firmware option
| Model | 65120B |
|---|
The Wayne-Kerr 65120B is a high-capacity LCR meter designed for precise component testing across a wide frequency range. It supports multiple test parameters with exceptional accuracy, making it versatile for both laboratory and production environments. The sturdy build ensures durability while offering fast measurement speeds for efficient workflows.
Engineered for flexibility, the 65120B easily adapts to routine checks as well as advanced analysis, providing reliable performance across diverse applications. Its speed and accuracy make it a trusted tool in demanding test setups.
Testwall can supply the used Wayne-Kerr 65120B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Wayne-Kerr 65120B.
