Audio Precision SYS-2712
| Attribute | Value |
|---|---|
| Frequency Range | 10 Hz to 204 kHz |
| Dynamic Range | Greater than 120 dB |
| Total Harmonic Distortion + Noise (THD+N) | Less than 0.0008% |
| Output Voltage Range | 100 mV to 26 Vrms (balanced) |
| Input Voltage Range | Up to 26 Vrms (balanced) |
| Analog Output Channels | 2 (stereo, balanced XLR) |
| Analog Input Channels | 2 (stereo, balanced XLR) |
| Digital Audio Interface | AES/EBU, S/PDIF, optical (TOSLINK) |
| Sample Rate Support | Up to 192 kHz |
| Control Interface | IEEE-488 (GPIB) and RS-232 |
Audio Precision SYS-2712 Audio Analyser Options:
- SYS-2712 - 2711 - Onboard Dolby Digital (Ac-3) Signal Generation For Sys-2722 And Sys-2720
- SYS-2712 - BUR - Analog Burst Sine Waves, Square Waves To 20 KHZ, Random And Pseudorandom Pink/Whire Noise
- SYS-2712 - FBP-XXX - Family Of Analog 1/3 Octave Bandpass Filters
- SYS-2712 - FIL-XXX - Family Of Analog Psophometric Noise Weighting Filters
- SYS-2712 - FLP-XXX - Family Of Analog Sharp Lowpass Filters
- SYS-2712 - G - Ieee-488 (Gpib) Interface
- SYS-2712 - IMD - Analog Intermodulation Distortion To Smpte/Din, Ccf And Dim/Tim Standards
- SYS-2712 - OPT-2020 - Lowpass Filter For Dac Measurements
- SYS-2712 - S-AES17 - Lowpass Filter For Aes17 Dac Measurements
- SYS-2712 - S2-PCI - Pci Interface Card W/Ap2700 Software
- SYS-2712 - S2-PCIE - S2-Pcipcie Interface Card W/Ap2700 Software
- SYS-2712 - S2-PCMCIA - Pcmcia Interface Card W/Ap2700 Software
- SYS-2712 - USB-APIB - Usb Interface Adapter W/Usb Cable, Ap2700 Software And Instructions
- SYS-2712 - W&F - Wow & Flutter To Iec/Din, Nab, Jis And Scrape Flutter Standards, Weighted Or Unweighted
| Model | SYS-2712 |
|---|
The Audio Precision SYS-2712, part of the award-winning and worldwide-standard 2700 series, is a PC-controlled audio test and measurement instrument offering unmatched distortion and noise performance, high-resolution analog inputs and outputs, DSP signal analysis and generation, and low-distortion hardware-implemented functions, ensuring precise measurements for advanced converter technologies and demanding audio applications.
It supports internal DSP analysis of internally-converted analog signals, DSP-generated analog outputs, new 192 kHz digital input/output capabilities in the series, and offers versatile configuration, triggering, and filtering options for audio equipment design, validation, and rigorous quality control workflows.
Testwall delivers used SYS-2712 units fully tested, with global shipping, expert technical support, optional calibration and repair services, dedicated inventory management, flexible financing options, and responsive customer care, ensuring superior reliability and service quality that outperforms competitors in performance and user satisfaction.
