Keysight (Agilent)
Keysight (Agilent) N1046A
75/85/100 GHz 1/2/4 Port Electrical Sampling Head
Up to 80 GHz (4-port) / Up to 64 GHz (8-port) Bandwidth
4 or 8 optical input channels Number of Channels
750 nm to 1650 nm Wavelength Range
Single-mode and multimode fiber optical inputs Input Connector Type
Up to 256 GSa/s (real-time) Sampling Rate
| Attribute | Value |
|---|---|
| Bandwidth | Up to 80 GHz (4-port) / Up to 64 GHz (8-port) |
| Number of Channels | 4 or 8 optical input channels |
| Wavelength Range | 750 nm to 1650 nm |
| Input Connector Type | Single-mode and multimode fiber optical inputs |
| Sampling Rate | Up to 256 GSa/s (real-time) |
| Optical Input Power Range | -20 dBm to +10 dBm |
| Interface Compatibility | Compatible with Infiniium UXR-Series oscilloscopes |
| Application | High-speed optical transceiver and coherent optical testing (400G, 800G) |
| Module Form Factor | External optical-to-electrical converter module |
| Supported Standards | IEEE 802.3, OIF CEI, 400G/800G Ethernet optical standards |
| Model | N1046A |
|---|
Keysight (Agilent) N1046A 75/85/100 GHz 1/2/4 Port Electrical Sampling Head Description: Maximum bandwidth: 75GHz, 85GHz or >100GHz (upgradeable) 1, 2 or 4 channels per module Ideal for analyzing 224 Gb/s high-speed signals Sample rate 250 kSa/s Requires DCA-X mainframe Keysight (Agilent) N1046A 75/85/100 GHz 1/2/4 Port Electrical Sampling Head
