Keysight (Agilent)
Keysight (Agilent) N2752A
6GHz Active Differential Probe
Keysight InfiniiVision 3000T X-Series and 4000 X-Series Oscilloscopes Compatibility
Differential Probe Amplifier Accessory Type
200 MHz Bandwidth
±1200 V (DC + Peak AC) Maximum Differential Input Voltage
80 dB at 60 Hz Common Mode Rejection Ratio (CMRR)
| Attribute | Value |
|---|---|
| Compatibility | Keysight InfiniiVision 3000T X-Series and 4000 X-Series Oscilloscopes |
| Accessory Type | Differential Probe Amplifier |
| Bandwidth | 200 MHz |
| Maximum Differential Input Voltage | ±1200 V (DC + Peak AC) |
| Common Mode Rejection Ratio (CMRR) | 80 dB at 60 Hz |
| Input Impedance | 8 MΩ / 7 pF (each input to ground) |
| Attenuation Ratios | 100:1 and 1000:1 (switchable) |
| Output Voltage | ±10 V into 1 MΩ load |
| Power Supply | Powered via probe interface on compatible oscilloscope (no external power required) |
| Safety Rating | CAT III 1000 V, CAT IV 600 V |
| Model | N2752A |
|---|
Keysight (Agilent) N2752A 6GHz Active Differential Probe Description: Keysight (Agilent) N2752A 6GHz Active Differential Probe
