Keysight (Agilent)
Keysight (Agilent) DSOX2024A
4 Ch 200 MHz InfiniiVision Oscilloscope
200 MHz Bandwidth
4 Number of Channels
2 GSa/s Sample Rate
1 Mpts Memory Depth
7-inch WVGA (800 x 480) color display Display
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 4 |
| Sample Rate | 2 GSa/s |
| Memory Depth | 1 Mpts |
| Display | 7-inch WVGA (800 x 480) color display |
| Vertical Resolution | 8-bit |
| Input Impedance | 1 MΩ ± 1% in parallel with 13 pF ± 3 pF |
| Waveform Update Rate | Up to 50,000 waveforms per second |
| Connectivity | USB Host, USB Device, LAN (LXI Core 2011) |
| Time Base Range | 5 ns/div to 50 s/div |
Keysight Technologies DSOX2024A Options:
- DSOX2024A - DSOX2WAVEGEN - WaveGen built-in 20 MHz function generator
- DSOX2024A - DSOX2MSO - MSO upgrade to add 8 integrated digital timing channels
- DSOX2024A - DSOX2MASK - Mask limit testing application
- DSOX2024A - DSOX2SGM - Segmented memory acquisition application
- DSOX2024A - DSOXEDK - Educator's Oscilloscope Training Kit
- DSOX2024A - DSOX2BW22 - Bandwidth upgrade from 100 MHz to 200 MHz (2 channel models)
- DSOX2024A - DSOX2BW24 - Bandwidth upgrade from 100 MHz to 200 MHz (4 channel models)
- DSOX2024A - DSOXLAN - LAN/VGA connection module
- DSOX2024A - DSOXGPIB - GPIB connection module
- DSOX2024A - N6456A - Rack mount kit
- DSOX2024A - N6457A - Soft carrying case and front panel cover
- DSOX2024A - N6458A - Hard copy manual
| Model | DSOX2024A |
|---|
The Keysight (Agilent) DSOX2024A offers 200 MHz bandwidth, 4 analog channels, 1 Mpts memory, and 200,000 wfms/s update rate. Expandable with function generator, voltmeter, and protocol options.
Great for teaching labs and entry-level signal capture.
Testwall can supply the used Keysight (Agilent) DSOX2024A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSOX2024A.
