Keysight (Agilent) N5222B-200
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 26.5 GHz |
| Number of Ports | 2-Port |
| Dynamic Range | Up to 132 dB |
| Output Power Range | -85 dBm to +13 dBm |
| Trace Noise (Magnitude) | 0.001 dB RMS |
| Measurement Speed | Up to 9.5 µs per point |
| Connector Type | 2.92 mm (K) connectors |
| IF Bandwidth Range | 1 Hz to 15 MHz |
| System Performance Option | Option 200: Extended Power Range and Bias Tees |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Number of Points | max. 100,003 |
| Measurement Parameters | S-parameters, group delay, phase noise (opt.) |
| Display | 12.1" LCD, 1280×800, touchscreen |
| Interfaces | LAN, 2× GPIB, USB, HiSLIP |
Available configurations
| Model | Ports | Frequency range | Configuration |
| N5222B-200 | 2-Port | 10 MHz to 26.5 GHz | 2.92 mm connectors |
| N5222B-201 | 2 | 10 MHz to 26.5 GHz | configurable test set |
| N5222B-205 | 2 | 900 Hz to 26.5 GHz | configurable test set, low-frequency extension to 900 Hz |
| N5222B-217 | 2 | 10 MHz to 26.5 GHz | configurable test set, source step attenuators, receiver step attenuators |
| N5222B-219 | 2 | 10 MHz to 26.5 GHz | configurable test set, source step attenuators, receiver step attenuators, built-in bias tees |
| N5222B-220 | 2 | 900 Hz to 26.5 GHz | source step attenuators, receiver step attenuators, low-frequency extension to 900 Hz |
| N5222B-400 | 4 | 10 MHz to 26.5 GHz | standard test set |
| N5222B-401 | 4 | 10 MHz to 26.5 GHz | configurable test set |
| N5222B-405 | 4 | 900 Hz to 26.5 GHz | configurable test set, low-frequency extension to 900 Hz |
| N5222B-417 | 4 | 10 MHz to 26.5 GHz | configurable test set, source step attenuators, receiver step attenuators |
| N5222B-419 | 4 | 10 MHz to 26.5 GHz | configurable test set, source step attenuators, receiver step attenuators, built-in bias tees |
| N5222B-420 | 4 | 900 Hz to 26.5 GHz | source step attenuators, receiver step attenuators, low-frequency extension to 900 Hz |
Keysight Technologies N5222B-200 Options:
- N5222B-200 - 200 - 2-port base model with standard test set
- N5222B-200 - 201 - To base model, adds front-panel jumpers and R1 receiver switch
- N5222B-200 - 205 - To base model (N5222B only), adds front-panel jumpers, R1 receiver switch, and low frequency extension (LFE) hardware
- N5222B-200 - 217 - To base model, adds front-panel jumpers, R1 receiver switch, and source and receiver attenuators (extended power range)
- N5222B-200 - 219 - To base model, adds front-panel jumpers, R1 receiver switch, source and receiver attenuators (extended power range), and bias-tees
- N5222B-200 - 400 - 4-port base model with standard test set
- N5222B-200 - 401 - To base model, adds front-panel jumpers and R1 receiver switch
- N5222B-200 - 417 - To base model, adds front-panel jumpers, R1 receiver switch, and source and receiver attenuators (extended power range)
- N5222B-200 - 419 - To base model, adds front-panel jumpers, R1 receiver switch, source and receiver attenuators (extended power range), and bias-tees
The Keysight (Agilent) N5222B-200 Vector Network Analyzer operates from 10 MHz to 26.5 GHz, offering high-precision S-parameter measurements through a 2-port, single-source test set. It features rugged 3.5 mm ports, high dynamic range (~127 dB), and +13 dBm output, with modern connectivity via USB, LAN, and GPIB.
Designed for RF engineers, it provides consistent, accurate results in demanding lab environments with XGA touch display usability and flexible test capabilities.
Testwall can supply the used Keysight (Agilent) N5222B-200, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N5222B-200.
