Leader
Leader 1603A
T.V Tester
1 Hz to 150 kHz Frequency Range
Sine, Square, Triangle Output Waveforms
Up to 20 Vp-p open circuit Output Amplitude
600 Ohms Output Impedance
±3% of full scale Frequency Accuracy
| Attribute | Value |
|---|---|
| Frequency Range | 1 Hz to 150 kHz |
| Output Waveforms | Sine, Square, Triangle |
| Output Amplitude | Up to 20 Vp-p open circuit |
| Output Impedance | 600 Ohms |
| Frequency Accuracy | ±3% of full scale |
| Sine Wave Distortion | Less than 1% (1 kHz reference) |
| Square Wave Rise Time | Less than 5 µs |
| DC Offset | ±10 V adjustable |
| Power Requirements | 100/120/220/240 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Leader 1603A Options:
- 1603A - LR-2450-01I - Rackmount Adapter for 1604A
- 1603A - LC-2027 - 5 BNC-BNC Cables
| Model | 1603A |
|---|
The 1603A includes dot clock to 65 MHz, H scan rates to 131 KHz, Analogue and TTL Outputs, Storage of 100 programs in ROM and 100 programs in RAM, easy guided raster programming, RS-232 interface, and standard or user generated test patterns.
