Rohde & Schwarz RTH1002 + RTH-B221 Handheld Oscilloscope, 100 MHz, 2 Channels
| Attribute | Value |
|---|---|
| Bandwidth | 100 MHz |
| Number of Channels | 2 |
| Sample Rate | 1.25 GSa/s |
| Memory Depth | 10 Mpts per channel |
| Vertical Resolution | 8-bit (up to 12-bit in high-resolution mode) |
| Display | 5.7-inch color touchscreen, 640 x 480 resolution |
| Battery Life | Up to 3 hours with RTH-B221 battery pack |
| Input Impedance | 1 MΩ || 15 pF |
| Timebase Range | 1 ns/div to 50 s/div |
| Protection Rating | IP51 (dust and drip-proof), CAT III 600 V / CAT II 1000 V safety rating |
Rohde & Schwarz RTH1002 + RTH-B221 Handheld Oscilloscope, 100 MHz, 2 Channels Options:
- RTH1002 - RTH-B1 - Mixed signal option, 250 MHz (additional 8 logic channels)
- RTH1002 - RTH-B221 - Upgrade of R&S®RTH1002 oscilloscopes to 100 MHz bandwidth
- RTH1002 - RTH-B222 - Upgrade of R&S®RTH1002 oscilloscopes to 200 MHz bandwidth
- RTH1002 - RTH-B223 - Upgrade of R&S®RTH1002 oscilloscopes to 350 MHz bandwidth
- RTH1002 - RTH-B224 - Upgrade of R&S®RTH1002 oscilloscopes to 500 MHz bandwidth
- RTH1002 - RTH-K1 - I2C/SPI serial triggering and decoding
- RTH1002 - RTH-K2 - UART/RS-232/RS-422/RS-485 serial triggering and decoding
- RTH1002 - RTH-K3 - CAN/LIN serial triggering and decoding
- RTH1002 - RTH-K9 - CAN-FD serial triggering and decoding (requires active RTH-K3 option as basis)
- RTH1002 - RTH-K10 - SENT serial triggering and decoding
- RTH1002 - RTH-K15 - History and segmented memory
- RTH1002 - RTH-K18 - Spectrum analysis
- RTH1002 - RTH-K19 - Advanced triggering
- RTH1002 - RTH-K33 - Frequency counter
- RTH1002 - RTH-K34 - Harmonic analysis
- RTH1002 - RTH-K200 - Wireless LAN, all countries except US and Canada
- RTH1002 - RTH-K200US - Wireless LAN, for US and Canada only
- RTH1002 - RTH-K201 - Web interface remote control
| Model | RTH1002 |
|---|
The Rohde and Schwarz RTH1002 with RTH-B221 is a high-performance handheld oscilloscope offering bandwidth from 60 MHz to 500 MHz, a sampling rate up to 5 Gsample/s, and memory depth up to 500 ksample or 50 Msample in segmented mode. Featuring 10-bit ADC resolution, it supports isolated channels rated CAT IV 600 V and CAT III 1000 V. It integrates multiple functions including a logic analyzer, protocol analyzer, multimeter, and more.
This oscilloscope is ideal for mobile and laboratory applications with capabilities like I²C/SPI/UART/CAN/LIN protocol analysis, harmonic analysis, and frequency counting. It provides robust data logging and advanced diagnostics in a compact form.
Testwall can supply the used Rohde and Schwarz RTH1002 with RTH-B221, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz RTH1002 with RTH-B221.
