Rohde & Schwarz ESCS30
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz – 300 MHz |
| Measurement Functions | EMI receiver for conducted and radiated interference measurements |
| Detector Types | Peak, Quasi-Peak, Average, RMS |
| IF Bandwidth | 200 Hz, 9 kHz, 120 kHz (CISPR-compliant bandwidths) |
| Dynamic Range | Up to 100 dB |
| Input Impedance | 50 Ω |
| Spurious Response | < –60 dBc (typical) |
| Standards Compliance | CISPR 16-1, VDE 0876, MIL-STD-461 |
| Interface / Connectivity | IEEE 488 (GPIB) for remote control and automation |
| Power Supply | 100–240 V AC, 50/60 Hz |
Rohde & Schwarz ESCS30 Options:
- ESCS30 - ESCS-B1 - Battery Controller
- ESCS30 - ESCS-B2 - Battery Pack
- ESCS30 - ESCS-B4 - IF Spectrum Analysis
- ESCS30 - ESCS-B5 - Tracking Generator (9 kHz to 2750 MHz, 50 Ω N female, 90 dBµV output level)
- ESCS30 - ESCS-B6 - OCXO Reference Oscillator
- ESCS30 - ESCS-B9 - RMS Detector
| Model | ESCS30 |
|---|
The Rohde & Schwarz ESCS30 EMI Receiver offers full compliance testing to CISPR and VDE standards, with high precision, overload immunity, wide dynamic range, and built-in time-domain analysis for interference tracking. It supports RFI voltage, power, and field-strength measurements, auto-detects frequencies, and uses quasi-peak/average detectors for final results. The ESCS30 also features automatic bandwidth selection, LISN phase control, and emission-maxima detection for reliable, efficient EMC testing.
Ideal for pre-certification testing, it identifies critical frequencies, optimizes product design, and cuts costs. RF analysis supports Spectrum Overview, Scan, and Channel Scan modes.
Testwall can supply the used Rohde & Schwarz ESCS30, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ESCS30.
