Tektronix
Tektronix TSG111
PAL Test Signal Generator
NTSC composite video signal Output Signal
1 V p-p into 75 Ω Output Amplitude
75 Ω Output Impedance
300 mV Sync Amplitude
3.579545 MHz Color Subcarrier Frequency
| Attribute | Value |
|---|---|
| Output Signal | NTSC composite video signal |
| Output Amplitude | 1 V p-p into 75 Ω |
| Output Impedance | 75 Ω |
| Sync Amplitude | 300 mV |
| Color Subcarrier Frequency | 3.579545 MHz |
| Signal Formats | Color bars, flat field, and multiburst test signals |
| Power Requirements | 115 V AC / 230 V AC, 50/60 Hz |
| Power Consumption | Approximately 10 W |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Dimensions (H x W x D) | 88.9 mm x 212.7 mm x 304.8 mm (3.5 in x 8.375 in x 12 in) |
| Model | TSG111 |
|---|
The Tektronix TSG111 is a cost-effective PAL test signal generator, ideal for servicing PAL TV systems. Its 10-bit digital signal architecture ensures high precision and stability typically seen only in premium models.
It offers comprehensive test signals to evaluate levels, linearity, frequency and phase response, clamp performance, and monitor alignment, making it indispensable for maintenance and diagnostics.
Testwall can supply the used Tektronix TSG111, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TSG111.
