Sorensen
Sorensen DCR600-8T
600-8A DC Power Supply
600 V Output Voltage
8 A Output Current
4800 W Output Power
208/240 VAC, Single Phase Input Voltage
47–63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 600 V |
| Output Current | 8 A |
| Output Power | 4800 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47–63 Hz |
| Voltage Regulation (Line/Load) | 0.05% / 0.05% |
| Current Regulation (Line/Load) | 0.1% / 0.1% |
| Output Ripple & Noise (RMS) | 0.1% or 15 mV, whichever is greater |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Forced Air Cooling |
Sorensen DCR600-8T Options:
- DCR600-8T - T1 - 208V STD. U.S. Voltage, 60Hz Input
- DCR600-8T - T2 - 380V STD. Continental Europe Voltage, 50Hz Input
- DCR600-8T - T3 - 415V STD. British Isles Voltage, 50Hz Input
- DCR600-8T - T4 - 440 Vac ±10% @ 60Hz Input
- DCR600-8T - T5 - 480 Vac ±10% @ 60Hz Input
- DCR600-8T - 1060247-1 - Chassis Slides (Optional)
- DCR600-8T - GPIB - Digital Programmer: Interface to GPIB Bus (Optional)
- DCR600-8T - MICRO-DAP - OVP Shutdown (Optional)
- DCR600-8T - SCR - Crowbar M5 Option
- DCR600-8T - M5 - Digital Metering: Standard
- DCR600-8T - M52 - Analog Metering: Add M52
| Model | DCR600-8T |
|---|
The Sorensen DCR600-8T is a DC Power Supply.
