Tektronix P2100
| Attribute | Value |
|---|---|
| Bandwidth | 100 MHz |
| Rise Time | 3.5 ns |
| Attenuation | 10X / 1X (switchable) |
| Input Resistance | 10 MΩ (10X) / 1 MΩ (1X) |
| Input Capacitance | 13.5 pF (10X) / 85 pF (1X) |
| Maximum Input Voltage | 300 V RMS CAT II (10X) / 150 V RMS CAT II (1X) |
| Cable Length | 1.2 m (4 ft) |
| Connector Type | BNC |
| Compensation Range | 15 pF to 35 pF |
| Compatible Oscilloscopes | Tektronix TBS1000, TDS1000/2000 Series and other BNC-input oscilloscopes |
| Model | P2100 |
|---|
The Tektronix P2100 is a durable passive voltage probe with selectable attenuation (×1/×10), offering 100 MHz bandwidth in ×10 mode and 7 MHz in ×1. It includes a 1.5 m cable with a hook-tip for secure connection, and provides low signal loading at ~10 MΩ/16 pF (×10) or ~1 MΩ/110 pF (×1). Rated for 300 V RMS (×10) and 150 V RMS (×1), this probe is compliant with UL3111‑1, CSA1010.1, and EN61010 safety standards.
Perfect for general electronics testing, the Tektronix P2100 supports versatile lab and field use with easy signal acquisition.
Testwall can supply the used Tektronix P2100, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P2100.
