Tektronix P6246
| Attribute | Value |
|---|---|
| Bandwidth | 400 MHz |
| Input Voltage Range | ±15V (DC + Peak AC) |
| Attenuation Ratio | 10X |
| Input Resistance | 1 MΩ |
| Input Capacitance | 9.5 pF (with compensation range 8–18 pF) |
| Rise Time | 875 ps |
| Cable Length | 1.3 m (4.3 ft) |
| Connector Type | BNC |
| Compatible Oscilloscopes | Tektronix oscilloscopes with BNC input (1 MΩ) |
| Operating Temperature | 0°C to +50°C |
Tektronix P6246 Options:
- P6246 - C3 - Calibration Service 3 Years
- P6246 - C5 - Calibration Service 5 Years
- P6246 - D1 - Calibration Data Report
- P6246 - D3 - Calibration Data Report 3 Years (with Option C3)
- P6246 - D5 - Calibration Data Report 5 Years (with Option C5)
- P6246 - R3 - Repair Service 3 Years
- P6246 - R5 - Repair Service 5 Years
| Model | P6246 |
|---|
The Tektronix P6246 Differential Probe offers 400 MHz bandwidth with <1 pF differential input capacitance and >60 dB CMRR. It connects to TEKPROBE® BNC interfaces and supports probing of high-speed signals in oscilloscopes and analyzers. The small probe head allows accurate probing of SMDs.
Ideal for applications like Gigabit Ethernet, RAMBUS, and disk drive diagnostics, the P6246 ensures precise pulse shape, jitter, and cross-talk testing in high-speed electronics.
Testwall can supply the used Tektronix P6246, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P6246.
