Tektronix P6703
| Attribute | Value |
|---|---|
| Wavelength Range | 700 nm to 1800 nm |
| Optical Input Connector | FC/PC |
| Electrical Output Connector | SMA |
| Maximum Input Power | +10 dBm (10 mW) |
| Conversion Gain | 700 V/W typical |
| Bandwidth | DC to 1 GHz |
| Detector Type | InGaAs Photodiode |
| Output Impedance | 50 Ohms |
| Power Supply | Powered via oscilloscope probe interface |
| Compatible Instruments | Tektronix oscilloscopes with TekProbe interface |
| Model | P6703 |
|---|
The Tektronix P6703 is a high-performance 700 MHz optical-to-electrical (O/E) converter designed for 1100–1700 nm wavelength detection. Featuring a rise time of ≤ 500 ps and conversion gain of ~1 V/mW at 1300 nm into 50 Ω, it ensures fast and accurate optical signal conversion. The unit supports FC-PC, SMA, or ST multimode fiber connectors and operates via TekProbe BNC or 1103 power supply.
Ideal for fiber optic communication testing, the P6703 supports up to ~10 mW non-destructive optical input and requires +15 V, +5 V, –5 V power via TekProbe interface.
Testwall can supply the used Tektronix P6703, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P6703.
