Tektronix P7225
| Attribute | Value |
|---|---|
| Bandwidth | 2.5 GHz |
| Rise Time | 140 ps |
| Input Impedance | 50 Ω |
| Dynamic Range | ±0.5 V |
| Attenuation Ratio | 10X |
| Maximum Input Voltage | ±15 V (DC + Peak AC) |
| Cable Length | 1.2 m (47 in) |
| Compatible Oscilloscopes | Tektronix TDS7000 and CSA7000 Series |
| Connector Type | SMA |
| Probe Type | Active Single-Ended Voltage Probe |
| Model | P7225 |
|---|
The Tektronix P7225 2.5GHz Active Probe delivers precise, high-speed signal acquisition with a 2.5GHz bandwidth, offering minimal signal loading and excellent dynamic range. Designed for advanced signal integrity analysis, it features low capacitance, high input impedance, and superior signal fidelity for demanding applications.
Ideal for use with high-performance oscilloscopes, the Tektronix P7225 supports accurate probing of high-speed digital circuits, RF signals, and other fast transitions while ensuring reliable measurement results.
Testwall can supply the used Tektronix P7225 2.5GHz Active Probe, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix P7225 2.5GHz Active Probe.
