Teledyne LeCroy WAVEPRO7300
| Attribute | Value |
|---|---|
| Bandwidth | 3 GHz |
| Sample Rate | 20 GS/s |
| Number of Channels | 4 |
| Memory Depth | Up to 48 Mpts/ch (with optional memory upgrade) |
| Vertical Resolution | 8 bits |
| Input Impedance | 50 Ω or 1 MΩ |
| Timebase Range | 20 ps/div to 1000 s/div |
| Display | 10.4-inch color LCD touchscreen |
| Trigger Types | Edge, Width, Glitch, Pattern, TV, Serial Protocol, and more |
| Connectivity | USB, Ethernet (LAN), GPIB (optional), CompactFlash |
Teledyne LeCroy WAVEPRO7300 Options:
- WAVEPRO7300 - -M - Memory Option: 8 Mpts/2 Ch, 4 Mpts/Ch
- WAVEPRO7300 - -L - Memory Option: 16 Mpts/2 Ch, 8 Mpts/Ch
- WAVEPRO7300 - -VL - Memory Option: 32 Mpts/2 Ch, 16 Mpts/Ch
- WAVEPRO7300 - -XL - Memory Option: 48 Mpts/2 Ch, 24 Mpts/Ch
- WAVEPRO7300 - GPIB-1 - IEEE-488 Remote Control Interface
- WAVEPRO7300 - WM-RHD - Removable Hard Drive Option
- WAVEPRO7300 - WM-CDRW - CD-RW Upgrade
- WAVEPRO7300 - CANbus TD - CAN Bus Trigger and Decode Test Package
- WAVEPRO7300 - DDM2 - Disk Drive Measurement Package
- WAVEPRO7300 - DFP2 - Digital Filter Package
- WAVEPRO7300 - ENET - Ethernet Test Software Package
- WAVEPRO7300 - JTA2 - Jitter and Timing Analysis Package
- WAVEPRO7300 - LECROYM1/ADV-1 - Advanced M1 Software Package for Jitter and Timing Measurements (1 seat)
- WAVEPRO7300 - LECROYM1/BASIC - Basic M1 Software Package for Jitter and Timing Measurements
- WAVEPRO7300 - PMA2 - Power Measure and Analysis Package
- WAVEPRO7300 - SDM - Serial Mask Package
- WAVEPRO7300 - USB2 - USB 2.0 Pre-Compliance Test Software Package
- WAVEPRO7300 - XDEV - Advanced Customization Package
- WAVEPRO7300 - XMAP - Master Analysis Package (includes JTA2, XMATH, XDEV)
- WAVEPRO7300 - XMATH - Advanced Math Software Package
- WAVEPRO7300 - AV - AntiVirus Software
| Model | WAVEPRO7300 |
|---|
The Teledyne LeCroy WavePro7300 offers 3 GHz bandwidth and up to 10 GS/s per channel (20 GS/s interleaved), ensuring precision in capturing high-speed signals. With up to 100 Mpts/channel memory in the XXL version, it provides extensive data handling capability. A jitter noise floor around 1 ps rms and an advanced timing measurement suite make it ideal for demanding signal analysis.
This oscilloscope is tailored for applications requiring detailed timing accuracy and signal integrity in faster digital environments, delivering powerful acquisition and measurement capabilities.
Testwall can supply the used Teledyne LeCroy WavePro7300, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Teledyne LeCroy WavePro7300.
