Keysight (Agilent)
Keysight (Agilent) 8990B
Peak Power Analyzer, 50 MHz - 40 GHz
100 kHz à 6 GHz Plage de fréquence
-70 dBm à +20 dBm Plage de puissance d'entrée
±0,04 dB (typique) Précision de mesure de puissance
50 Ohms Impédance d'entrée
2 canaux d'entrée indépendants Nombre de canaux
| Attribut | Valeur |
|---|---|
| Plage de fréquence | 100 kHz à 6 GHz |
| Plage de puissance d'entrée | -70 dBm à +20 dBm |
| Précision de mesure de puissance | ±0,04 dB (typique) |
| Impédance d'entrée | 50 Ohms |
| Nombre de canaux | 2 canaux d'entrée indépendants |
| Interface de communication | USB, LAN (LXI), GPIB |
| Affichage | Écran LCD couleur intégré |
| Tension d'alimentation | 100 V à 240 V CA, 50/60 Hz |
| Plage de température de fonctionnement | 0 °C à 55 °C |
| Dimensions (L x H x P) | 426 mm x 88 mm x 348 mm |
Keysight (Agilent) 8990B Options:
- 8990B - 800 - Standard hard drive, installed
- 8990B - 801 - Removable hard drive, installed
- 8990B - U01 - With USB host
- 8990B - U02 - Without USB host
- 8990B - 1CM - Rackmount kit, 8U full rack
- 8990B - 1FP - Multi-pulse analysis software, fixed perpetual license
- 8990B - 1A7 - Compliant calibration test data - ISO17025, printed
- 8990B - A6J - Certificate of compliance calibration - ANSI/NCSL Z540, printed
- 8990B - 0BF - English language programming guide, printed
- 8990B - 0BK - English language user and programming guide, printed
- 8990B - 0BW - English language service guide, printed
- 8990B - ABJ - Japanese user guide and English programming guide, printed
- 8990B - 0B0 - Do not include printed manuals
- 8990B - ABA - English language user guide, printed
- N1923A - 105 - Fixed cable option length, 1.5 m (5 ft)
- N1923A - 106 - Fixed cable option length, 3 m (10 ft)
- N1924A - 105 - Fixed cable option length, 1.5 m (5 ft)
- N1924A - 106 - Fixed cable option length, 3 m (10 ft)
| Model | 8990B |
|---|
RENT KEYSIGHT 8990B (AGILENT) Peak Power Analyzer (call for availability)
The Keysight 8990B (Agilent) Peak Power Analyzer offers faster measurement speed and greater measurement accuracy in key applications such as radar pulse analysis and wireless pulse measurement. Designed with both ease of use and high performance in mind the Agilent 8990B Peak Power Analyzer saves you time and effort allowing you to focus on the important details. When used with a compatible peak power sensor, this analyzer is able to measure the dynamic or time-dependent aspects of RF and microwave power.
Features and Specifications of the Keysight 8990B (Agilent) Peak Power Analyzer include:
- Provides internal and external trigger functions
- 20X zooming capability with dual Screen Zoom Window
- Internal Zeroing and Calibration
- Touchscreen Capability
- Frequency Range: 50 MHz to 40 GHz (sensor dependent)
- Dynamic range: -35 to +20dBm (CW) and -25 to +20dBm (Pulse)
- Short System Rise/ Fall time of 5nsec (-20 to +20dBm)
- 100 MSa/ sec continuous sampling with >1500 readings/ sec
- Channels are compatible with U2000 Series power sensors connected using the USB hosts
- Provide 15 Pulse Characterization Measurement
- Automated pulse delay measurement between channels
- 4 channels (RF and Video):
- RF Channels are 1 and 4
- Frequency Range: 50 MHz to 40 GHz
- Dynamic Range: €“35 dBm to +20 dBm
- Measurement Unit: linear (Watt) or Log (dBm) selectable
- Video Bandwidth: 150 MHz
- Max Pulse Width: 150 MHz
- Max Pulse Repetition Rate: 10 MHz
- Input Coupling: 50 O
- Vertical Scale:
- 0.01 dB/div to 100 dB/div in 1-2-5 sequence or any arbitrary scaling, user defined
- 1 uW/div to 1 kW/div in 1-2-5 sequence or any arbitrary scaling, user defined
- Offset: ± 99 dBm with 0.01 dB resolution
- Video Channels are 2 and 3
- Video Inputs allow the simultaneous analysis of time-domain control signals
- Video Bandwidth: 1GHz
- Input Impedance:
- 50 O ± 2.5%,1 MO ± 1% (11 pF typical)
- Input Coupling:
- 1 MO: AC (3.5 Hz), DC
- 50 O: DC
- Vertical Scale:
- 1 MO: 1 mV/div to 5 V/div in 1-2-5 sequence or any arbitrary scaling, user defined
- 50 O: 1 mV/div to 1 V/div in 1-2-5 sequence or any arbitrary scaling, user defined
- DC Gain Accuracy: ± 5% of full scale at full resolution on channel scale ± 5 °C from cal temp
- Offset Accuracy: ± (1.25% of channel offset +1% of full scale + 1 mV)
