Keysight (Agilent) E4413A
| Attribute | Value |
|---|---|
| Frequency Range | 26.5 GHz to 40 GHz |
| Power Range | -70 dBm to +20 dBm |
| Connector Type | 2.92 mm (K-type) male |
| Sensor Type | CW Power Sensor (Diode-based) |
| Measurement Uncertainty | ±0.9% (at 50 MHz reference) |
| Dynamic Range | 90 dB |
| Compatible Power Meters | Keysight E4418B, E4419B, EPM Series, EPM-P Series |
| Operating Temperature Range | 0°C to 55°C |
| VSWR (Voltage Standing Wave Ratio) | 1.15 maximum (at 26.5–40 GHz) |
| Power Sensor Interface | Keysight E-Series compatible interface with EEPROM calibration data |
Keysight Technologies E4413A Options:
- E4413A - Opt A6J - ANSI/NCSL Z540-1-1994 Certificate of Calibration
| Model | E4413A |
|---|
The Keysight (Agilent) E4413A CW diode power sensor operates across a frequency range of 50 MHz to 26.5 GHz, with extended options to 33 GHz. It offers an exceptional dynamic range of -70 dBm to +20 dBm and up to 400 readings per second with compatible meters like E4416A. The sensor features EEPROM-stored calibration factors, linearity, and temperature compensation data for enhanced accuracy.
This sensor is compatible with EPM, EPM-P, and P-series power meters, delivering reliable measurements with low mismatch uncertainty due to excellent SWR. Its traceability to NIST ensures dependable performance in RF testing environments.
Testwall can supply the used Keysight (Agilent) E4413A CW diode power sensor, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E4413A CW diode power sensor.
